Magnet Fitment System

Introducing the Magnet Fitment System from Mobile Solutions. Watch the how to video here!



Using small, round neodymium magnets for custom fabricated interior and audio-related panel mounting is a fairly recent trend. The advantages are ease of panel removal for serviceability or access, but also that it’s virtually infinite in the amount of times the panel can be removed and reinstalled without wear and tear on the fastener as in traditional plastic panel retainers and “Christmas tree” clips. Neodymium magnets provide an ideal hidden fastening system. It’s classy and innovative.



The problem when using these magnets for panel attachments is common size drill bits are not precision-sized for a secure press fit and leave an angled bottom of the drilled hole. This means the mounting hole (also called the “pocket hole”) ends up larger than round magnet’s outer diameter and without a flat countersink at the bottom of the hole. Ultimately when using common drill bits, the magnet lacks a tight mechanical fit once placed into the countersunk hole. A super-tight fit is critical because of the force of attraction between these magnets. For example, a common 3/8” bit will drill slightly larger than the diameter of the magnet and with a bottom surface that matches the drill bit cutting angle (not flat). The added effort for adhesion is absolutely required to secure the magnet without pulling out of the countersink hole. In addition, because magnets require a specific polarity orientation to attract to one another (rather than oppose), positioning the magnets with a backward polarity orientation is a common mistake. The Mobile Solutions Magnet Fitment System solves all these problems with a solution-driven approach.



The custom CNC-machined Magnet Match™ countersink bits in the Mobile Solutions Magnet Fitment System are precisely sized in diameter to provide the maximum mechanical fitment of Mobile Solutions neodymium magnets along with a flat finish at the bottom of the countersink hole. Next, the prefect-sized acrylic Smart Mag Alignment Plates™ used with a rubber mallet ensure the magnets are inserted into the countersink hole with the utmost accuracy and precision. Markings for North and South polarity on the Smart Mag Alignment Plates™ ensure magnets don’t get placed in a backward (opposing) polarity orientation. Using this approach, added adhesion with glue, silicone or other compounds, although recommended, is not always necessary.



Added adhesion (such as CA glue) really depends on the material of choice. Softer plastics and MDF may benefit from the addition of glue to resist the magnet pull strength, whereas hard plastics or aluminum will not require any extra adhesion because of the tight mechanical fit the Magnet Fitment System provides. It’s as simple as drilling a pilot hole through both surfaces (fixed surface and removable panel), countersinking the magnet pocket hole, mounting the magnet with correct polarity orientation and you’re done. We recommend using a North magnet polarity orientation for the fixed panel and a South orientation for the removable panel to remain consistent in your builds. We also recommend using a drill press over a handheld drill.



The Magnet Fitment System also features the iconic Mobile Solutions-style organizational tray. Keep the components of the kit organized and easily identify which tools are needed during your working process. It fits easily into our slat wall tray holder or grid wall tray holder, just like our well-known router bit tray systems.



With the Mobile Solutions Magnet Fitment System and neodymium magnets (available in four sizes), you can be sure that your first time drilling and countersinking the magnet pocket hole is the only time you’ll need to do it. No do-overs required!



Features:

  • Precision CNC-Machined Magnet Match™ Countersink Bits to match exact magnet tolerances – not ‘off the shelf’ sizing
  • Countersink Diameter NOMINAL Sizes: 1/4”, 3/8”, 1/2" & 3/4" all with a 3/8” Shank
  • Use with a drill press or handheld drill (drill press is recommended for best results)
  • Flat bottom design on Countersink Bits for maximum glue adhesion (if using glue)
  • Smart Mag Alignment Plates™  with embedded magnets for accurate placement
  • Markings on Smart Mag Alignment Plates™  indicate polarity orientation (North/South)
  • Sturdy 1/2” Acrylic on Smart Mag Alignment Plates™  allows long-term use with rubber mallet
  • Smart Magnet System is designed for multiple types of plastic and wood substrates, as well as aluminum
  • Signature Mobile Solutions tray provides easy organization and features a QR code that links to the “How To” learning video



Uses:

  • Door and trim panel inserts that can be removed to expose threaded fasteners
  • Subwoofer enclosure grilles that can be removed to service the subwoofer
  • Amplifier rack covers that can be removed for servicing the electronics/fuses
  • Console sides that can be removed for access to wiring, mechanical linkages, etc.
  • Creating hidden storage compartments for safety items like jumper cables or first aid kits
  • Much, much more – only limited by the fabricator’s imagination



Benefits:

  • Save precious fabrication and install time
  • More predictable outcomes on custom projects
  • Invisible fasteners – no screw caps or hard-to-reach mounting hardware
  • Expands creativity of mounting options and aesthetic designs
  • Enhances serviceability of equipment and parts behind panels



What’s Included in the Kit:

  • (4) Magnet Mounting Countersink Bits in sizes 1/4”, 3/8”, 1/2" & 3/4"
  • (4) 1/2” Thick  Acrylic Smart Mag Alignment Plates™  with embedded magnets
  • (4) 1/8” Centering Drill Bits
  • Custom Organizer Tray



Specifications:

  • Max RPM of Countersink Bits – 870 RPM
  • Number of pieces (including tray) 13 pcs.



Neodymium magnets are not included with this kit. Check out the options for magnets HERE

Magnet Fitment System

SKU: SI-MFS
$299.99 Regular Price
$249.99Sale Price

    Contact Us
